Upgrade your dash with the Kenwood DMX7509XDS, a 9" HD capacitive floating display receiver with wireless or wired Apple CarPlay and Android Auto. Your favourite apps appear on the big screen, so you can navigate, stream music, make calls and read or reply to messages by touch or by voice, using Siri or Google Assistant. Wireless mirroring lets you share Android phone content with passengers, and Apple devices can be mirrored through the HDMI input.
The 1280 x 720 anti-glare display has a flexible ball mount floating design with 5-point vertical height adjustment, so you can set the screen where it suits your dash. The capacitive touchscreen works like a smartphone, and you can customise the menus and widgets. Built-in DAB+ digital radio brings you digital stations, and Bluetooth 5.3 with HFP 1.7 gives you reliable hands-free calling and music streaming.
Shape your sound with the 13-band graphic EQ and digital time alignment, and add an amplifier through three pairs of 3V RCA pre-outs (front, rear and subwoofer). Two camera inputs (front and rear) let you add external cameras, and the HD rear camera input suits Kenwood’s optional CMOS-740HD and CMOS-150HD cameras. The unit is iDatalink Maestro ready and steering remote ready, so you can retain factory controls with the right adapter.
Key features:
- 9" HD (1280 x 720) capacitive floating display with anti-glare screen
- Wired and wireless Apple CarPlay
- Wired and wireless Android Auto
- Siri and Google Assistant voice control
- Wireless mirroring for Android, and Apple mirroring via HDMI
- Flexible ball mount floating design with 5-point vertical screen height adjustment
- Built-in DAB+ digital radio
- Bluetooth 5.3 with HFP 1.7 (calls and music)
- 13-band graphic EQ, digital time alignment and 2/3-way crossover
- 3 pairs of 3V RCA pre-outs (front, rear, subwoofer)
- 2 camera inputs (front and rear), HD rear camera ready
- HDMI input (D type)
- Rear USB port with 2.1A charging
- iDatalink Maestro ready
- Direct steering remote ready
- 1DIN chassis, 117.3mm mounting depth
Specifications:
- Screen: 9" capacitive, 1280 x 720, anti-glare, white illumination
- Chassis: 1DIN floating, not a short chassis, 117.3mm mounting depth
- Power output: 22W x 4
- Pre-outs: 6 channels (front, rear, subwoofer), 3V
- EQ: 13-band graphic, with digital time correction and 2/3-way crossover
- USB: 1 rear port, 2.1A charging
- Bluetooth: 5.3, HFP 1.7, single active phone connection
- Radio: built-in DAB+
- Navigation, CD and DVD: not included
Connectivity notes:
- Wireless CarPlay and Android Auto can be interrupted by things like phone firmware updates, low power or battery optimisation modes, and radio interference in busy areas.
- Android Auto works with a wide range of Android phones, but Kenwood can’t guarantee every device. Check your phone’s compatibility before you buy.
Enjoy a big, adjustable display, wireless smartphone connectivity and built-in DAB+ radio with the Kenwood DMX7509XDS, a feature-packed receiver for everyday driving.
